Color mixing scale Sartorius EVO1S1N1–C
Maximum load 7.5/1.0 kg – Readability 0.1/0.05 g – Without calibration – Without ATEX
Non-verified mixing scale with 0.1 g/0.05 g readability, USB interface and stainless steel platform. Ideal for paint labs and workshops without legal-for-trade requirements.
-
Delivery time: 3-4 weeks
- Purchase on invoice
- Authorized dealer and service partner
- Original accessories available
Found this product cheaper elsewhere?
Send us a comparison offer from an authorised dealer — we'll review it and match the price. Guaranteed.
- 1 Submit your offer. By email to [email protected] — incl. model, item no. and price.
- 2 Review by our team. We compare model, scope of delivery and conditions (identical new goods, authorised dealer).
- 3 Response within 24 h. Binding price match — including consultation, 4-year warranty and service.
Valid for commercial orders. Excluded: B-stock, promotional and discontinued items.
Configure Your Scale
Not sure whether weighing range, verification or configuration are right for you? Our shop team is happy to help.
Description
PMA Evolution – Precision Scale for Paint Mixing and Industrial Formulations
The PMA Evolution by Sartorius is a high-precision paint mixing scale for professional use in industry, trades, and laboratories. It is ideally suited for recipe-based dosing of liquid and powder components – for example, in paint shops or formulation labs. Thanks to its modern touchscreen design, versatile applications, and USB data integration, it significantly simplifies daily operations. The scale is also available in a verified version and suitable for use in Ex-Zones 1 & 2.
The high-contrast touchscreen is easy to read even from a distance. Thanks to the glass-covered interface, stainless steel weighing pan, and optional protective covers, the scale is hygienic and quick to clean. Power and data transfer are handled by a single USB cable – ideal for workshop environments.
Verified version available – PMA Evolution can be supplied with EU verification in accordance with OIML R76.
Integrated functions like recalculation in the event of overdosing or factor-based adjustment for different container sizes support precise and efficient workflows. The scale is powered via USB or optionally by a plug-in power supply.
Technical Specifications
| Specification | Value |
|---|---|
| Maximum Capacity | 7500 g |
| Readability | 0.1 g (switchable to 0.05 g – only available on non-verified models) |
| Repeatability | ±0.1 g |
| Linearity | ±0.2 g |
| Platform Size | Ø 233 mm |
| Display | Touchscreen, high contrast, visual feedback |
| Keypad | Touch operation |
| Interfaces | USB Type B (SBI, XBPI) |
| Operating Temperature | 5 – 40 °C |
| Functions | Recipe management, calibration, dosing aid, lock function |
Accessories & Extensions
Note: Ex-Link accessories are intended exclusively for use with EX versions of the PMA Evolution.
| Accessory | Description |
|---|---|
| Protective cover – display | For display unit, 10-pack |
| Protective cover – stand | For device stand, 10-pack |
| Protective cover – platform | For weighing platform, 10-pack |
| USB cable (3 m) | For power supply and data transfer |
| Grounding cable (2 m) | For EX protection and discharge |
| Ex-Link Converter | For Zone 1, interface converter |
| Link cable 10 m | From Ex-Link converter to scale |
| Link cable 20 m | Longer version for extended setups |
| Link cable 30 m | Maximum length converter-to-scale |
| USB plug-in power supply | External mains power adapter |
| Plug adapter set | EU, US, UK – for international use |
Typical Applications
- Automotive paint shops and workshops
- Industrial paint and coating production
- Color formulation laboratories
- Explosion-protected areas (Zone 1 & 2)
Visit ESSMANN Waagen – we will be happy to support you in integrating this scale into your operational workflows.
Technical Specifications
| Ambient temperature (Max) in °C: | 40 |
|---|---|
| Ambient temperature (min) in °C: | 5 |
| Design of the scale: | Dual range scale |
| Digit increment [d] in g: | 0,1/0,05 |
| Display type: | touch screen |
| Functions: | Formulation, Counting function |
| Housing depth in mm: | 340 |
| Housing height in mm: | 340 |
| Housing width in mm: | 232 |
| Interfaces series: | USB |
| Power supply: | plug-in power supply |
| Protection class: | IP40 |
| Weighing range [Max] in kg: | 1/7,5 |
